8-1437653-1 | TE Connectivity
PCB terminal, 16 pole, AWG 22 to 12, 25 A, screw connection, black, 8-1437653-1
Unit Price (€ / pc.)
10.8647 € *
Available in 5 Days: 180 pcs. - if ordered today
Total Price:
10.86 € *
Price list
Quantity
Price per unit*
1 pcs.
10.8647 €
5 pcs.
10.3054 €
10 pcs.
9.6390 €
25 pcs.
8.7822 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB terminal, 8-1437653-1, TE Connectivity
Barrier strip, Tri-Barrier, Printed circuit pin, Wire-to-Board, 16 Position, 9.53 mm Centerline, 1 Row, 600 V / 300 V.
Applications
- Machine control
- Power supplies
- Test & measurement
- Automation equipment
- Security/alarm devices
- Garage door openers
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | screw connection | |
| Width | 17.78 mm | |
| Colour | black | |
| Pin number | 16 pole | |
| AWG cross-section | AWG 22 to 12 | |
| Assembly | THT | |
| Height | 15.88 mm | |
| Rated current | 25 A | |
| Cable cross-section | 0.326-3.31 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
