796689-2 | TE Connectivity

Name: PCB terminal, 2 pole, pitch 5 mm, AWG 30-12, 17.5 A, screw connection, black, 796689-2
Brand: TE Connectivity
SKU: 38P7486
Availability: InStock

PCB terminal, 2 pole, pitch 5 mm, AWG 30-12, 17.5 A, screw connection, black, 796689-2

Order No.: 38P7486

EAN: 4099891039547

MPN:

796689-2

Image may differ

Key Specification:

Pin number 2 pole

Grid 5 mm

Cable cross-section 0.05-3.0 mm²

AWG cross-section AWG 30-12

Download Datasheet Technical specifications

NCNR (non cancelable / non returnable)

Unit Price (€ / pc.)

1.2138 € *

Standard delivery time from the manufacturer is: 12 Weeks

Total Price:

1.21 € *

Price list

Quantity

Price per unit*

1 pcs.

1.2138 €

10 pcs.

1.1305 €

25 pcs.

1.0472 €

50 pcs.

0.9520 €

*incl. VAT plus shipping costs

Subject to prior sale

Description

PCB terminal block, 796689-2, TE Connectivity

Wire Protection: With, Terminal Block Connector Type: Header, Connector System: Wire-to-Board, Connector & Contact Terminates To: Printed Circuit Board, Threaded Flange: Without, Number of Positions: 2, Number of Rows: 1, Wire Entry Angle: 35°, Current Rating (Max): 17.5 A, Voltage Rating: 300 VAC, Interlock: With, Contact Base Material: Brass, Contact Current Rating (Max): 17.5 A, Screw Flange: Without, Connector Mounting Type: Board Mount, Housing Material: PA 66, Centerline (Pitch): 5 mm, PCB Tail Length: 3.8 mm, Wire Size: 30 – 12 AWG, Wire Size: 0.05 – 3 mm², Operating Temperature Range: -40 – 110 °C, Circuit Application: Power & Signal, Comment: 15A Field Wiring

Technical specifications

Filter	Property	Value
	Pin number	2 pole
	Grid	5 mm
	Cable cross-section	0.05-3.0 mm²
	AWG cross-section	AWG 30-12
	Rated current	17.5 A
	Rated voltage	300 V
	Connection	screw connection
	Assembly	THT
	Colour	black
