284049-3 | TE Connectivity
PCB terminal, 3 pole, pitch 7.62 mm, AWG 30-12, 15 A, screw connection, green, 284049-3
Order No.: 38P7471
EAN: 4099891039394
MPN:
284049-3
Unit Price (€ / pc.)
8.6513 € *
Available in 5 Days: 1,280 pcs. - if ordered today
Total Price:
8.65 € *
Price list
Quantity
Price per unit*
1 pcs.
8.6513 €
10 pcs.
8.0325 €
25 pcs.
7.4970 €
50 pcs.
6.8187 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB terminal block, 284049-3, TE Connectivity
Wire Protection: With, Terminal Block Connector Type: Plug, Connector System: Wire-to-Board, Connector & Contact Terminates To: Wire & Cable, Stacking Configuration: Side Stackable, Number of Positions: 3, Number of Rows: 1, Wire Entry Angle: Side, Current Rating (Max): 15 A, Voltage Rating: 300 VAC, Interlock: Without, Contact Base Material: Phosphor Bronze, Contact Current Rating (Max): 15 A, Screw Flange: Without, Housing Material: PA 66, Centerline (Pitch): 7.62 mm, Wire Size: 30 – 12 AWG, Wire Size: 0.05 – 3 mm², Operating Temperature Range: -40 – 105 °C, Circuit Application: Power & Signal.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 15 A | |
| Rated voltage | 300 V | |
| Cable cross-section | 0.05-3.0 mm² | |
| Pin number | 3 pole | |
| Grid | 7.62 mm | |
| AWG cross-section | AWG 30-12 | |
| Colour | green | |
| Connection | screw connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85366910 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | No |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
