282858-4 | TE Connectivity
PCB terminal, 4 pole, pitch 10 mm, AWG 30-12, 24 A, cage clamp, green, 282858-4
Order No.: 71P7046
EAN: 4099891630836
MPN:
282858-4
Unit Price (€ / pc.)
2.5228 € *
Available in 5 Days: 3,795 pcs. - if ordered today
Total Price:
2.52 € *
Price list
Quantity
Price per unit*
1 pcs.
2.5228 €
10 pcs.
2.3324 €
25 pcs.
2.1777 €
50 pcs.
1.9873 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB terminal, 282858-4, TE Connectivity
PCB Terminal block, Header, Wire-to-Board, 4 Position, 10 mm Centerline, 1 Row, Side wire entry angle, 30 - 12 AWG Wire size.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 4 pole | |
| Grid | 10 mm | |
| Cable cross-section | 0.05-3 mm² | |
| AWG cross-section | AWG 30-12 | |
| Rated current | 24 A | |
| Rated voltage | 600 V | |
| Width | 10 mm | |
| Height | 19 mm | |
| Connection | cage clamp | |
| Assembly | THT | |
| Colour | green |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| RoHS conform | Yes |
