1986723-5 | TE Connectivity
PCB terminal, 5 pole, pitch 3.5 mm, AWG 30-14, 9 A, push-in spring connection, green, 1986723-5
Order No.: 71P4112
EAN: 4099891629205
MPN:
1986723-5
Unit Price (€ / pc.)
9.8175 € *
Standard delivery time from the manufacturer is: 14 Weeks
Total Price:
9.82 € *
Price list
Quantity
Price per unit*
1 pcs.
9.8175 €
5 pcs.
9.3177 €
10 pcs.
8.7108 €
25 pcs.
7.9492 €
*incl. VAT plus shipping costs
Subject to prior sale
Spring terminal block, 1986723-5, TE Connectivity
The 1986723-5 provides a quick and easy way for installers in the field to mate wires without the use of special tools. This product offers space savings for additional configurations and provide flexibility in the design of board layouts in tight spaces.
Features
- Fast wire connections
- Mates with industry standard headers on the same centerline spacing
Applications
- Wire-to-board applications requiring field wiring termination
- Industrial control
- HVAC Controls
- Applications subject to certain types of vibrations
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 30-14 | |
| Pin number | 5 pole | |
| Colour | green | |
| Cable cross-section | 0.05-2 mm² | |
| Connection | push-in spring connection | |
| Grid | 3.5 mm | |
| Rated voltage | 300 V | |
| Rated current | 9 A | |
| Width | 11.65 mm | |
| Height | 20.75 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
