1986300-8 | TE Connectivity
PCB terminal, 8 pole, pitch 5 mm, AWG 24-14, 16 A, cage clamp, green, 1986300-8
Order No.: 71P4009
EAN: 4099891628376
MPN:
1986300-8
Unit Price (€ / pc.)
13.2090 € *
Available in 5 Days: 1,904 pcs. - if ordered today
Total Price:
13.21 € *
Price list
Quantity
Price per unit*
1 pcs.
13.2090 €
10 pcs.
12.1618 €
50 pcs.
10.9361 €
100 pcs.
9.8413 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB Terminal, 1986300-8, TE Connectivity
The wire entry cavity and the activating screw head are on the same plane which is parallel to the plug in direction.
Applications
- Industrial Control
- HVAC controls
- Communications equipment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | green | |
| Width | 27.1 mm | |
| Cable cross-section | 0.2-2 mm² | |
| AWG cross-section | AWG 24-14 | |
| Pin number | 8 pole | |
| Connection | cage clamp | |
| Height | 14.9 mm | |
| Rated voltage | 300 V | |
| Rated current | 16 A | |
| Grid | 5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
