1546074-3 | TE Connectivity

Name: PCB terminal, 3 pole, pitch 5.08 mm, AWG 30-12, 17.5 A, screw connection, black, 1546074-3
Brand: TE Connectivity
SKU: 38P7473
Availability: InStock

PCB terminal, 3 pole, pitch 5.08 mm, AWG 30-12, 17.5 A, screw connection, black, 1546074-3

Order No.: 38P7473

EAN: 4099891039417

MPN:

1546074-3

Image may differ

Key Specification:

Pin number 3 pole

Grid 5.08 mm

Cable cross-section 0.05-3.0 mm²

AWG cross-section AWG 30-12

Download Datasheet Technical specifications

Unit Price (€ / pc.)

2.6061 € *

Available in 5 Days: 1,648 pcs. - if ordered today

Total Price:

2.61 € *

Price list

Quantity

Price per unit*

1 pcs.

2.6061 €

10 pcs.

2.4276 €

25 pcs.

2.2610 €

50 pcs.

2.0587 €

*incl. VAT plus shipping costs

Subject to prior sale

Description

PCB terminal block, 1546074-3, TE Connectivity

Wire Protection: With, Terminal Block Connector Type: Header, Connector System: Wire-to-Board, Connector & Contact Terminates To: Printed Circuit Board, Threaded Flange: Without, Number of Positions: 3, Number of Rows: 1, Wire Entry Angle: 35°, Current Rating (Max): 17.5 A, Voltage Rating: 300 VAC, Interlock: With, Contact Base Material: Brass, Contact Current Rating (Max): 17.5 A, Screw Flange: Without, Connector Mounting Type: Board Mount, Housing Material: PA 66, Centerline (Pitch): 5.08 mm, PCB Tail Length: 3.8 mm, Wire Size: 30 – 12 AWG, Wire Size: 0.05 – 3 mm², Operating Temperature Range: -40 – 110 °C, Circuit Application: Power & Signal.

Technical specifications

Filter	Property	Value
	Width	12.5 mm
	Grid	5.08 mm
	AWG cross-section	AWG 30-12
	Rated current	17.5 A
	Rated voltage	300 V
	Cable cross-section	0.05-3.0 mm²
	Colour	black
	Pin number	3 pole
	Assembly	THT
	Height	15 mm
	Connection	screw connection
