1-284414-2 | TE Connectivity
PCB terminal, 12 pole, pitch 3.5 mm, AWG 30-12, 12 A, cage clamp, green, 1-284414-2
Order No.: 71P1806
EAN: 4099891627263
MPN:
1-284414-2
Unit Price (€ / pc.)
8.7465 € *
Available in 5 Days: 3,163 pcs. - if ordered today
Total Price:
8.75 € *
Price list
Quantity
Price per unit*
1 pcs.
8.7465 €
10 pcs.
8.1158 €
25 pcs.
7.5803 €
50 pcs.
6.8901 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB Terminal, 1-284414-2, TE Connectivity
The 1-284414-2 has a rising cage clamp which promotes numerous reliable connections and disconnections at field installations. This product is interchangeable with pc board footprint is fully compatible with existing Industry Standards.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Width | 13 mm | |
| Grid | 3.5 mm | |
| AWG cross-section | AWG 30-12 | |
| Rated current | 12 A | |
| Rated voltage | 300 V | |
| Cable cross-section | 0.05-3 mm² | |
| Colour | green | |
| Pin number | 12 pole | |
| Assembly | THT | |
| Height | 8.2 mm | |
| Connection | cage clamp |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| Substance description | Lead |
