1-2834014-6 | TE Connectivity
PCB terminal, 6 pole, pitch 5 mm, AWG 20-16, 10 A, spring-clamp connection, green, 1-2834014-6
Order No.: 39P9505
EAN: 4099891039721
MPN:
1-2834014-6
Unit Price (€ / pc.)
1.6303 € *
Available: 0 pcs.
Available in 5 Days: 1,372 pcs.
Leadtime: 21 Weeks **
Total Price:
1.63 € *
Price list
Quantity
Price per unit*
1 pcs.
1.6303 €
10 pcs.
1.4875 €
50 pcs.
1.3328 €
100 pcs.
1.2019 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB terminal block, 1-2834014-6, TE Connectivity
Terminal Block Connector Type: Receptacle, Connector System: Wire-to-Board, Sealable: No, Connector & Contact Terminates To: Printed Circuit Board, Number of Positions: 6, Number of Rows: 1, Wire Entry Angle: Side, Current Rating (Max): 10 A, Voltage Rating: 300 VAC, Color: Green, Contact Base Material: Copper, Contact Current Rating (Max): 10 A, Mounting Angle: Vertical, Housing Material: High Temperature Nylon or Polyester, Wire Size: 20 – 16 AWG, Operating Temperature Range: -40 – 105 °C, Circuit Application: Power & Signal.
Technical specifications
| Connection | Federklemmanschluss | |
| AWG cross-section | AWG 20-16 | |
| Colour | grün | |
| Rated voltage | 300 V | |
| Rated current | 10 A | |
| Pin number | 6-polig | |
| Grid | 5 mm |
Download
Logistics
| Country of origin | IN |
| Customs tariff number | 85366910 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
