1-1986375-0 | TE Connectivity
PCB terminal, 10 pole, pitch 3.81 mm, AWG 30-14, 11 A, cage clamp, green, 1-1986375-0
Order No.: 71P1101
EAN: 4099891626273
MPN:
1-1986375-0
Unit Price (€ / pc.)
16.3625 € *
Available in 5 Days: 400 pcs. - if ordered today
Total Price:
16.36 € *
Price list
Quantity
Price per unit*
1 pcs.
16.3625 €
10 pcs.
15.1963 €
25 pcs.
14.1848 €
50 pcs.
12.8877 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB Terminal, 1-1986375-0, TE Connectivity
The 1-1986375-0 is a left hand plug that allows additional configurations of wire access angles to be applied to vertical and Right angle headers. This product is end to end stackable without loss of centerline spacing.
Applications
- Wire-to-board applications requiring field wiring termination
- Industrial controls
- HVAC controls
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 30-14 | |
| Width | 10.35 mm | |
| Grid | 3.81 mm | |
| Rated voltage | 300 V | |
| Cable cross-section | 0.05-2 mm² | |
| Colour | green | |
| Rated current | 11 A | |
| Connection | cage clamp | |
| Height | 12.6 mm | |
| Pin number | 10 pole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
