1-1546108-0 | TE Connectivity
PCB terminal, 10 pole, pitch 5.08 mm, AWG 30-12, 15 A, screw connection, green, 1-1546108-0
Order No.: 38P7467
EAN: 4099891039356
MPN:
1-1546108-0
Unit Price (€ / pc.)
5.7001 € *
Standard delivery time from the manufacturer is: 11 Weeks
PCB terminal block, 1-1546108-0, TE Connectivity
Wire Protection: With, Terminal Block Connector Type: Plug, Connector System: Wire-to-Board, Connector & Contact Terminates To: Wire & Cable, Threaded Flange: Without, Number of Positions: 10, Number of Rows: 1, Wire Entry Angle: Side, Current Rating (Max): 15 A, Voltage Rating: 300 VAC, Interlock: Without, Contact Base Material: Phosphor Bronze, Contact Current Rating (Max): 15 A, Screw Flange: Without, Housing Material: PA 66, Centerline (Pitch): 5.08 mm, Wire Size: 30 – 12 AWG, Wire Size: 0.05 – 3 mm², Operating Temperature Range: -40 – 105 °C, Circuit Application: Power & Signal, Marking Color: Black.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 5.08 mm | |
| Pin number | 10 pole | |
| Height | 15.5 mm | |
| Colour | green | |
| Rated current | 15 A | |
| Cable cross-section | 0.05-3.0 mm² | |
| Connection | screw connection | |
| Assembly | THT | |
| AWG cross-section | AWG 30-12 | |
| Depth | 18.4 mm | |
| Rated voltage | 300 V | |
| Width | 50.8 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
