282809-4 | TE Connectivity
Socket header, 4 pole, pitch 10.16 mm, angled, green, 282809-4
Order No.: 59F888
MPN:
282809-4
Unit Price (€ / pc.)
7.2590 € *
Standard delivery time from the manufacturer is: 11 Weeks
Total Price:
7.26 € *
Price list
Quantity
Price per unit*
1 pcs.
7.2590 €
10 pcs.
6.7473 €
50 pcs.
6.2118 €
100 pcs.
5.6525 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB terminal block, 282809-4, TE Connectivity
4 Position PCB Terminal Block, Receptacle, Wire-to-Board, 10.16 mm Centerline, 1 Row, 180° Wire Entry Angle, 30 - 12 AWG, 0.05 - 3 mm² Wire.
Technical specifications
| Colour | green | |
| contact surface | tin-plated | |
| Rated current | 15 A | |
| Grid | 10.16 mm | |
| Pin number | 4 pole | |
| Version | pin header | |
| Orientation | angled | |
| Connection | screw connection | |
| Contact type | pin | |
| Rated voltage | 600 V | |
| Number of rows | 1 |
Download
Logistics
| Country of origin | IT |
| Customs tariff number | 85366930 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
