1589462-6 | TE Connectivity
Socket header, 5 pole, pitch 0.64 mm, straight, black, 1589462-6
Order No.: 34P3029
EAN: 4099889910056
MPN:
1589462-6
SSL005L2HN
Unit Price (€ / pc.)
267.8095 € *
Available in 5 Days: 52 pcs. - if ordered today
Total Price:
267.81 € *
Price list
Quantity
Price per unit*
1 pcs.
267.8095 €
2 pcs.
233.9540 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB Connection System, 1589462-6, TE Connectivity
Wire-to-Board, Printed Circuit Board, Shrouded, Horizontal, 5 Position
Technical Data
- Connector Mounting Type: Board Mount
- Contact Type: Female
- Contact Base Material: Beryllium Copper
- Housing Material: LCP (Liquid Crystal Polymer)
- Housing Color: black
- Orientation: angled
- Number of positions: 5
- Centerline (Pitch): 0.64 mm
- PCB Mount Retention: Without
- Sealable: No
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Breakable | No | |
| Type of locking | No | |
| contact surface | tin-lead | |
| Grid | 0.64 mm | |
| Connection plating | tin-lead | |
| Pin number | 5 pole | |
| Version | socket header | |
| Additional parts | equipped | |
| Orientation | straight | |
| Connection | SMD | |
| Contact type | socket | |
| Rated voltage | 150 V | |
| Number of rows | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CZ |
| Customs tariff number | 85366910 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | No |
