1-1744417-9 | TE Connectivity
Socket housing, 19 pole, pitch 2.5 mm, straight, natural, 1-1744417-9
Unit Price (€ / pc.)
0.2237 € *
Standard delivery time from the manufacturer is: 21 Weeks
Total Price:
22.37 € *
Price list
Quantity
Price per unit*
100 pcs.
0.2237 €
250 pcs.
0.2059 €
500 pcs.
0.1916 €
1000 pcs.
0.1725 €
*incl. VAT plus shipping costs
Subject to prior sale
Power connector, 1-1744417-9, TE Connectivity
The 1-1744417-9 is a economy power connector that provides a comprehensive connectivity solution with vertical and Right angle headers, optional TPA retainers, wire-to-wire and wire-toboard options and a range of resin materials that include types meeting. This product has asymmetrical terminals that can only be loaded into housing in one way.
Features
- Housing locking latch
- Polarization tabs
- Standard or low insertion force (LIF) terminals
- Anti-fretting contact lubricant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2.5 mm | |
| Contact type | socket | |
| Version | socket housing | |
| Rated voltage | 250 V | |
| Orientation | straight | |
| Type of locking | Yes | |
| Additional parts | unequipped | |
| Number of rows | 1 | |
| Colour | natural | |
| Pin number | 19 pole | |
| Connection | crimp connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85389099 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
