1-1734598-4 | TE Connectivity
Pin header, 14 pole, pitch 1.25 mm, straight, natural, 1-1734598-4
Order No.: 71P0771
EAN: 4099891716882
MPN:
1-1734598-4
Unit Price (€ / pc.)
0.9877 € *
Available in 5 Days: 1,952 pcs. - if ordered today
Total Price:
252.85 € *
Price list
Quantity
Price per unit*
256 pcs.
0.9877 €
576 pcs.
0.9758 €
*incl. VAT plus shipping costs
Subject to prior sale
Mount header, 1-1734598-4, TE Connectivity
The 1-1734598-4 offers vertical and horizontal (Right angle) connector mounting for versatility, and the square-peg technology enables product compatibility with industry standard products.
Features
- Polarized
- Square termination post
- Provides design flexibility
- Prevents stubbing contacts
Applications
- Business and retail equipment
- Consumer devices
- Industrial
- Automotive
- Medical
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 1.25 mm | |
| contact surface | nickel-plated | |
| Contact type | pin | |
| Connection | solder connection | |
| Connection plating | tin-plated | |
| Rated voltage | 100 V | |
| Orientation | straight | |
| Number of rows | 1 | |
| Type of locking | No | |
| Pin number | 14 pole | |
| Additional parts | equipped | |
| Colour | natural | |
| Version | pin header | |
| Rated current | 3 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
