Combo jacks, 1-1909119-4, TE Connectivity
Connector & connector components type: connector, Modular jack & plug interface type: RJ45 over Single USB, Modular jacks & plugs products: Combo jacks, Modular connector style: Jack, Grounding options: PCB Ground, Multiple port configuration: Stacked, Port matrix configuration: 2x1, Port configuration: Single port, Status indicator type: LED, Connector contact density: Standard, Shell Plating Material: Brass, Connector profile: Standard, Modular jack latch orientation: Standard - latch down, Shield material: Brass, Shield Plating Material: Nickel, Contactunderplating material: Nickel, Contact base material: Phosphor bronze, Contact current rating (Max): 1 A, 5 A, PCB contact termination area plating material: Gold Flash, Termination method to printed circuit board: Through hole - solder, Panel mount feature: Without, Connector mounting type: Board mount, Housing color: Black, Housing material: PBT GF, Centerline (Pitch): 1.02 mm, 2 mm, 2.5 mm, Operating temperature range: -40-85 °C, Shielded: Yes, Circuit application: Signal, UL flammability rating: UL 94V-0, Performance category: Cat 3, Packaging method: Box & Tray, Tray
