8-1393485-7 | TE Connectivity
D-Sub socket, 9 pole, standard, equipped, straight, IDC connection, 8-1393485-7
Insulation displacement connectors series Sub-D DIN 41652, type TE Connectivity/AMP ..-139.
For ribbon cables with 1.27 mm grid; Test voltage: contact/contact 780 VRMS, contact/ground 1200 VRMS. Operating current at +20 °C: 2.0 A. Air gaps and creepage distances: contact/ground 2.2 mm, contact/contact 0.7 mm, for 0.09 to 0.14 mm² stranded wire conductor cross-sections (AWG 26/AWG 28) or solid wire 0.25 to 0.34 mm² (AWG 28/AWG 30). Dimension H: 9-pole/18.6 mm, 15-pole/26.9 mm, 25-pole/40.6 mm, 37-pole/57.1 mm. The other electrical and mechanical values correspond with the specifications at the beginning of the series.
Sub-D female cable connectors, straight, with 4-40 UNC thread, type ..-139.
Insulated displacement terminals, for ribbon cable and single cables.
Type: 8-1393485-7, 9-pole
| Filter | Property | Value |
|---|---|---|
| Pin number | 9 pole | |
| Version | socket header | |
| Contact connection | IDC connection | |
| Pole image | standard | |
| Additional parts | equipped | |
| Assembly | straight | |
| Type of locking | threaded insert 4-40 UNC | |
| Attachment (rear panel) | through hole |
| Property | Value |
|---|---|
| Country of origin | PL |
| Customs tariff number | 85366990 |
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
