5554349-1 | TE Connectivity
D-Sub socket, 24 pole, standard, equipped, straight, IDC connection, 5554349-1
Order No.: 37P3009
EAN: 4099889787672
MPN:
5554349-1
Unit Price (€ / pc.)
14.7203 € *
Standard delivery time from the manufacturer is: 10 Weeks
D-Sub socket, 5554349-1, TE
IDC D-Sub Connector, Receptacle, 30 – 26 AWG solid wire size, 0.05 – 0.13 mm² solid wire size, 28 AWG stranded wire.
Features
- Unsealable
- Shielded
- Contact base material: Copper alloy
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2.16 mm | |
| Pin number | 24 pole | |
| Pole image | standard | |
| Version | socket header | |
| Assembly | straight | |
| Additional parts | equipped | |
| Type of locking | knurled screw | |
| Contact connection | IDC connection |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
