1-2157481-1 | TE Connectivity
D-Sub socket, 9 pole, unequipped, straight, crimp connection, 1-2157481-1
Order No.: 34P1566
EAN: 4099889783391
MPN:
1-2157481-1
Unit Price (€ / pc.)
53.5976 € *
Standard delivery time from the manufacturer is: 12 Weeks
Box Mount D-Sub Connector, 1-2157481-1, TE Connectivity
Product Type: Connector, Connector and Housing Type: Receptacle, Connector System: Cable-to-Cable, D-Sub Shell Size: 1, Sealable: Yes, Preloaded: No, Number of Positions: 9, Power/Signal/Coax Combination: No, Shell Plating Material: Cadmium, Non-Magnetic: No, Contact Base Material: Copper Alloy, Contact Type: Socket, D-Sub Contact Size: 20, Contact Current Rating (Max): 7.5 A, Mounting Hole Diameter: 2.92 – 3.18 mm, Centerline (Pitch): 2.77 mm, Operating Temperature Range: -55 – 125 °C, ULTRA-LITE Connector: No, Circuit Application: Signal, NASA Qualification: No.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2.77 mm | |
| Pin number | 9 pole | |
| Version | socket header | |
| Assembly | straight | |
| Additional parts | unequipped | |
| Contact connection | crimp connection |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366910 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | not_specified |
| Date of RoHS guidelines | 3/31/15 |
