2825206-1 | TE Connectivity

Name: Pin contact, 1.31 mm², AWG 16, crimp connection, 2825206-1
Brand: TE Connectivity
SKU: 71P6985
Price: 0.12 EUR
Availability: OutOfStock

Pin contact, 1.31 mm², AWG 16, crimp connection, 2825206-1

Order No.: 71P6985

EAN: 4099889984910

MPN:

2825206-1

Image may differ

Key Specification:

Version pin contact

Cable cross-section 1.31 mm²

AWG cross-section AWG 16

Contact connection crimp connection

Contact material copper alloy

Ordering Information:

not to be sold to private customers

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.1190 € *

Available: 0 pcs.

Available in 5 Days: 10,500 pcs.

Leadtime: 1 Week **

Add to Cart

Total Price:

0.12 € *

Price list

Quantity

Price per unit*

3500 pcs.

0.1190 €

7000 pcs.

0.1107 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Pin contact, 2825206-1, TE Connectivity

Power contact, Contact, 600 VAC, Tin, 16 AWG Wire size, 1.31 mm² Wire size, Wire & Cable, Crimp, Power, Pin, -40 - 105 °C.

Technical specifications

	Version	pin contact
	AWG cross-section	AWG 16
	Insulation diameter	1.5-3.1 mm
	Contact connection	crimp connection
	Contact material	copper alloy
	Contact surface Connection range	tin-plated
	Contact surface mating area	tin-plated
	Cable cross-section	1.31 mm²
