1-1337445-0 | TE Connectivity

BNC socket 50 Ω, solder connection, straight, 1-1337445-0

Order No.: 37P2198
EAN: 4099889829358
MPN:
1-1337445-0
Series: BNC
1-1337445-0 TE Connectivity Coaxial Connectors
Image may differ
Unit Price (€ / pc.)
7.5446 € *
Available: 12 pcs.
Total Price:
7.54 € *
Price list
Quantity
Price per unit*
1 pcs.
7.5446 €
10 pcs.
6.6164 €
100 pcs.
5.8072 €
250 pcs.
5.5930 €
1000 pcs.
5.2360 €
*incl. VAT plus shipping costs
Subject to prior sale

RF Connector, 1-1337445-0, TE Connectivity

RF Interface: BNC, RF Connector Style: Jack, Connector System: Cable-to-Board, Sealable: No, Connector & Contact Terminates To: Printed Circuit Board, Number of Positions: 1, PCB Mount Orientation: Vertical, Number of Coaxial Contacts: 1, Impedance: 50 Ω, Body Insulation: With, Body Material: Brass, Body Plating Material: Silver, RF Connector Center Contact Plating Material: Silver, RF Connector Center Contact Material: Brass, Termination Method to Printed Circuit Board: Through Hole - Solder, Termination Post & Tail Length: 4 mm, PCB Mount Retention: With, RF Connector Coupling Mechanism: Bayonet, Connector Mounting Type: Board Mount, RF Contact Captivation Method: Mechanical, Detent: With, PCB Thickness (Recommended): 3.2 mm, RF Connector Mated Outer Diameter (Approximate): 14.53 mm, Height Above PC Board: 13 mm, Operating Temperature Range: -65 – 165 °C, Operating Frequency: 4 GHz, Packaging Quantity: 50, Packaging Method: Bag, Grade: Professional, Dielectric Material: PTFE

Technical specifications
Filter Property Value
Connector BNC
Impedance 50 Ω
Design straight
Version socket
Contact connection solder connection
Contact material brass
Logistics
Property Value
Country of origin DE
Customs tariff number 85366990
Compliance
Property Value
SVHC free No
Substance description Lead
Date of RoHS guidelines 3/31/15
RoHS conform Yes
