368530-1 | TE Connectivity
Plug, unequipped, 6 pole, straight, 3 rows, black, 368530-1
Unit Price (€ / pc.)
1.9754 € *
Available: 0 pcs.
Next delivery: 400 pcs. on 2025-10-17
Leadtime: 23 Weeks **
Plug housing, 368530-1, TE Connectivity
Connector system: wire-to-wire, Sealable: yes, Hybrid connector: no, Number of positions: 6, Number of rows: 3, Body material: PBT GF, Primary product color: black, Mating alignment type: polarized, Centerline (pitch): 4.8 mm, Row-to-row spacing: 5.6 mm, Operating temperature (max): 70 °C, 75 °C, 80 °C, 85 °C, 90 °C, 100 °C, 105 °C, Operating temperature range: -30-105 °C, UL flammability rating: UL 94V-2, Packaging method: bag, Connector position assurance capable: no
Technical specifications
| Contact type | plug | |
| Grid | 4.8 mm | |
| Additional parts | unequipped | |
| Type of locking | Yes | |
| Number of rows | 3 | |
| Colour | black | |
| Version | straight | |
| Pin number | 6 pole | |
| Rated voltage | 250 V |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85389091 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
