TDK

ACP3225-102-2P-T000 | TDK

Common mode filter, 100 MHz, 1.5 A, 60 V (DC), 60 VDC, 4.1 µH, faston plug 6.3 mm, ACP3225-102-2P-T000

default S
default L
Total price
(0.74 € * / pcs.)
0.00 €
Next delivery: 3,000 pcs. on 2023-03-14
Quantity
Price per unit*
5 pcs.
0.74 €
25 pcs.
0.67 €
125 pcs.
0.60 €
500 pcs.
0.55 €
1000 pcs.
0.50 €
*incl. VAT plus shipping costs
Description

Product by TDK at Bürklin Elektronik

Suppressor filter, ACP3225-102-2P-T000, TDK

Features

  • Chip type common mode filter for DC power supply lines
  • Can reduce power consumption and improve EMC suppression because of low direct current resistance and excellent common mode impedance
  • Compatible with high-density portable devices, which are always being made smaller and lighter, because the height has been reduced
  • Operating temperature range: –40 to +85 °C (Does not include self-heating. The product can be used up to 105 °C including self-heating )

Applications

  • Power line noise countermeasure for various electronic equipment
  • Noise countermeasure for AC adapter lines and battery lines for note PCs, portable game machines, and mobile phones
Technical specifications
ohmic resistance 1000 Ω
Connection faston plug 6.3 mm
Version Common mode filter
Rated Voltage 60 VDC
Inductance per line 0.0041 mH
integrated switch No
max. frequency 100 MHz
max. operating temperature 85 °C
min. operating temperature -40 °C
With fuse No
Rated voltage (DC) 60 V
Rated current 1.5 A
Show similar products (0)
Logistics
Customs tariff number 85363010
Original Packaging Reel with 1,000 pieces
Compliance
Guidline date 3/31/15
RoHS confom Yes
SVHC date 1/16/20
SVHC free Yes
Variations
1 item with 2 variations
Item description
Price list
Total
ohmic resistance
Version
Rated Voltage
max. frequency
Connection
min. operating temperature
Rated voltage (DC)
max. operating temperature
Rated current
Common mode filter, 100 MHz, 1.5 A, 60 V (DC), 60 VDC, 4.1 µH, faston plug 6.3 mm, ACP3225-102-2P-T000
Order No.:
 46D6731
Manufacturer:
 TDK
Manufacturer SKU
 ACP3225-102-2P-T000
5 pcs.
0.74 €
25 pcs.
0.67 €
125 pcs.
0.60 €
500 pcs.
0.55 €
1000 pcs.
0.50 €
0.00 € *
Next delivery: 3,000 pcs. on 2023-03-14
1000 Ω
Common mode filter
60 VDC
100 MHz
faston plug 6.3 mm
-40 °C
60 V
85 °C
1.5 A
Common mode filter, 100 MHz, 2 A, 60 V (DC), 60 VDC, 1.7 µH, SMD, ACP3225-501-2P-T000
Order No.:
 46D6732
Manufacturer:
 TDK
Manufacturer SKU
 ACP3225-501-2P-T000
1000 pcs.
0.50 €
0.00 € *
Currently not in stock, we will order for you
500 Ω
Common mode filter
60 VDC
100 MHz
SMD
-40 °C
60 V
85 °C
2 A
