SPM6530T-3R3M-HZ | TDK

Choke, SMD, 3.3 µH, 6.9 A, SPM6530T-3R3M-HZ

default S
front S
side S
default L
front L
side L
Total price
(0.74 € * / pcs.)
0.00 €
Currently not in stock, we will order for you
Quantity
Price per unit*
1000 pcs.
0.74 €
*incl. VAT plus shipping costs
Description

Product by TDK at Bürklin Elektronik

SMD choke, SPM6530T-3R3M-HZ, TDK

Features

  • Magnetic shield type wound inductor for power circuits using a metallic magnetic material
  • Compared to ferrite wound type inductors, it is possible to achieve large current, low Rdc, and compactness
  • Low inductance variance in high-temperature environments with good DC superimposition characteristics
  • Metallic magnetic material is used, and the structure has an integrated molded coil, so hum noise is lower than with ferrite core adhesive coils

Applications

  • Automotive equipment
  • Car navigation
  • Car audio
Technical specifications
Version SMD choke
Design SMD
Width 6.5 mm
DC current 6.9 A
DC resistance 0.0297 Ω
Height 3 mm
Inductance 0.0033 mH
Length 7.1 mm
Measuring frequency 0.1 MHz
Saturation current 6.4 A
Tolerance ±20 %
Show similar products (0)
Logistics
Customs tariff number 85045000
Compliance
Guidline date 3/31/15
RoHS confom Yes
SVHC date 1/16/20
SVHC free Yes
Variations
1 item with 12 variations
Item description
Price list
Total
Design
Version
Width
Length
Tolerance
Height
Inductance
DC current
DC resistance
Choke, SMD, 4.7 µH, 5.6 A, SPM6530T-4R7M-HZ
Order No.:
 72D1352
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-4R7M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.0047 mH
5.6 A
0.03938 Ω
Choke, SMD, 1 µH, 14.4 A, SPM6530T-1R0M-HZ
Order No.:
 72D1347
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-1R0M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.001 mH
14.4 A
0.00781 Ω
Choke, SMD, 680 nH, 16 A, SPM6530T-R68M-HZ
Order No.:
 72D1356
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-R68M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.00068 mH
16 A
0.00539 Ω
Choke, SMD, 3.3 µH, 6.9 A, SPM6530T-3R3M-HZ
Order No.:
 72D1351
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-3R3M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.0033 mH
6.9 A
0.0297 Ω
Choke, SMD, 1.5 µH, 11.6 A, SPM6530T-1R5M-HZ
Order No.:
 72D1348
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-1R5M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.0015 mH
11.6 A
0.01067 Ω
Choke, SMD, 5.6 µH, 5.4 A, SPM6530T-5R6M-HZ
Order No.:
 72D1353
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-5R6M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.0056 mH
5.4 A
0.04125 Ω
Choke, SMD, 6.8 µH, 4.8 A, SPM6530T-6R8M-HZ
Order No.:
 72D1354
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-6R8M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.0068 mH
4.8 A
0.05995 Ω
Choke, SMD, 2.2 µH, 8.4 A, SPM6530T-2R2M-HZ
Order No.:
 72D1350
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-2R2M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.0022 mH
8.4 A
0.01903 Ω
Choke, SMD, 15 µH, 3.3 A, SPM6530T-150M-HZ
Order No.:
 72D1346
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-150M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.015 mH
3.3 A
0.1199 Ω
Choke, SMD, 10 µH, 4.2 A, SPM6530T-100M-HZ
Order No.:
 72D1345
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-100M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.01 mH
4.2 A
0.08635 Ω
Choke, SMD, 22 µH, 2.6 A, SPM6530T-220M-HZ
Order No.:
 72D1349
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-220M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.022 mH
2.6 A
0.2002 Ω
Choke, SMD, 470 nH, 20.5 A, SPM6530T-R47M-HZ
Order No.:
 72D1355
Manufacturer:
 TDK
Manufacturer SKU
 SPM6530T-R47M-HZ
1000 pcs.
0.74 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
6.5 mm
7.1 mm
±20 %
3 mm
0.00047 mH
20.5 A
0.00363 Ω
