SPM5030T-2R2M | TDK

Choke, SMD, 2.2 µH, 6.1 A, SPM5030T-2R2M

default S
front S
side S
default L
front L
side L
Total price
(1.00 € * / pcs.)
0.00 €
Currently not in stock, we will order for you
Quantity
Price per unit*
500 pcs.
1.00 €
*incl. VAT plus shipping costs
Description

Product by TDK at Bürklin Elektronik

SMD choke, SPM5030T-2R2M, TDK

Features

  • Magnetic shield type wound inductor for power circuits using a metallic magnetic material
  • Compared to ferrite wound type inductors, it is possible to achieve large current, low Rdc, and compactness
  • Low inductance variance in high-temperature environments with good DC superimposition characteristics
  • Operating temperature range: -40 to +125°C

Applications

  • Note PCs
  • HDDs
  • VRMs
  • Compact power supply modules
Technical specifications
Version SMD choke
Design SMD
Width 5 mm
DC current 6.1 A
DC resistance 0.02123 Ω
Height 3 mm
Inductance 0.0022 mH
Length 5.2 mm
Measuring frequency 0.1 MHz
Saturation current 4.9 A
Tolerance ±20 %
Show similar products (0)
Logistics
Customs tariff number 85045000
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
1 item with 9 variations
Item description
Price list
Total
Design
Version
Width
Length
Tolerance
Height
Inductance
DC current
DC resistance
Choke, SMD 5030, 200 nH, 22.2 A, SPM5030T-R20M
Order No.:
 75D1818
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-R20M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD 5030
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.0002 mH
22.2 A
0.00231 Ω
Choke, SMD, 2.2 µH, 6.1 A, SPM5030T-2R2M
Order No.:
 72D1334
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-2R2M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.0022 mH
6.1 A
0.02123 Ω
Choke, SMD, 4.7 µH, 4.7 A, SPM5030T-4R7M
Order No.:
 72D1338
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-4R7M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.0047 mH
4.7 A
0.0495 Ω
Choke, SMD 5030, 350 nH, 16.6 A, SPM5030T-R35M
Order No.:
 75D1819
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-R35M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD 5030
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.00035 mH
16.6 A
0.00429 Ω
Choke, SMD, 3.3 µH, 6 A, SPM5030T-3R3M
Order No.:
 72D1336
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-3R3M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.0033 mH
6 A
0.02948 Ω
Choke, SMD 5030, 750 nH, 11.3 A, SPM5030T-R75M
Order No.:
 75D1820
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-R75M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD 5030
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.00075 mH
11.3 A
0.00935 Ω
Choke, SMD, 1.5 µH, 8 A, SPM5030T-1R5M
Order No.:
 72D1332
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-1R5M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.0015 mH
8 A
0.0168 Ω
Choke, SMD, 470 nH, 14 A, SPM5030T-R47M
Order No.:
 72D1342
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-R47M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.00047 mH
14 A
0.00594 Ω
Choke, SMD 5030, 1 µH, 10.1 A, SPM5030T-1R0M
Order No.:
 75D1817
Manufacturer:
 TDK
Manufacturer SKU
 SPM5030T-1R0M
500 pcs.
1.00 €
0.00 € *
Currently not in stock, we will order for you
SMD 5030
SMD choke
5 mm
5.2 mm
±20 %
3 mm
0.001 mH
10.1 A
0.01144 Ω
