NLCV32T-220K-EFD | TDK
Choke, SMD 1210, 22 µH, 300 mA, NLCV32T-220K-EFD
Not suitable for new designs
Unit Price (€ / pc.)
0.1190 € *
Standard delivery time from the manufacturer is: 18 Weeks
SMD choke, NLCV32T-220K-EFD, TDK
Features
- Resin mold type wound inductor for decoupling circuits
- Operating temperature range: -40 to +105°C
- Ferrite core
Applications
- Automotive equipment
- Navigation systems
- Car audio
- Electronic throttle control (ETC)
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inductance | 22 µH | |
| Length | 3.2 mm | |
| Quality Q | Q 15 | |
| Height | 2.2 mm | |
| Version | SMD choke | |
| Measuring frequency | 2.52 MHz | |
| Tolerance | ±10 % | |
| Width | 2.5 mm | |
| DC resistance | 770 mΩ | |
| DC current | 300 mA | |
| Design | SMD 1210 |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 2,000 pieces |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
