TDK

MLZ1608M3R3WT000 | TDK

Choke, SMD 0603, 3.3 µH, 400 mA, MLZ1608M3R3WT000

default S
front S
side S
default L
front L
side L
Total price
(0.05 € * / pcs.)
0.00 €
Currently not in stock, we will order for you
Quantity
Price per unit*
4000 pcs.
0.05 €
*incl. VAT plus shipping costs
Description

Product by TDK at Bürklin Elektronik

SMD choke, MLZ1608M3R3WT000, TDK

Features

  • Low DC resistance
  • Compatible with wide frequency band noise, from low to high frequency
  • Ferrite core
  • Compliant with AEC-Q200

Applications

  • Smart phones
  • Tablet terminals
  • Video games
  • Portable memory audio devices
  • PNDs, WLANs, SSDs
Technical specifications
Version SMD choke
Design SMD 0603
Width 0.8 mm
DC current 0.4 A
DC resistance 0.33 Ω
Height 0.8 mm
Inductance 0.0033 mH
Length 1.6 mm
Measuring frequency 2 MHz
Saturation current 0.12 A
Tolerance ±20 %
Show similar products (0)
Logistics
Customs tariff number 85045000
Compliance
Guidline date 3/31/15
RoHS confom Yes
SVHC date 1/16/20
SVHC free Yes
Variations
1 item with 7 variations
Item description
Price list
Total
Design
Version
Width
Length
Tolerance
Height
Inductance
DC current
DC resistance
Choke, SMD 0603, 15 µH, 200 mA, MLZ1608M150WT000
Order No.:
 72D1239
Manufacturer:
 TDK
Manufacturer SKU
 MLZ1608M150WT000
4000 pcs.
0.05 €
0.00 € *
Currently not in stock, we will order for you
SMD 0603
SMD choke
0.8 mm
1.6 mm
±20 %
0.8 mm
0.015 mH
0.2 A
1.5 Ω
Choke, SMD 0603, 22 µH, 0.1 mA, MLZ1608M220WT000
Order No.:
 75D0651
Manufacturer:
 TDK
Manufacturer SKU
 MLZ1608M220WT000
4000 pcs.
0.05 €
0.00 € *
Currently not in stock, we will order for you
SMD 0603
SMD choke
0.8 mm
1.6 mm
±20 %
0.8 mm
0.022 mH
0.0001 A
2.4 Ω
Choke, SMD 0603, 3.3 µH, 400 mA, MLZ1608M3R3WT000
Order No.:
 72D1241
Manufacturer:
 TDK
Manufacturer SKU
 MLZ1608M3R3WT000
4000 pcs.
0.05 €
0.00 € *
Currently not in stock, we will order for you
SMD 0603
SMD choke
0.8 mm
1.6 mm
±20 %
0.8 mm
0.0033 mH
0.4 A
0.33 Ω
Choke, SMD 0603, 10 µH, 250 mA, MLZ1608M100WT000
Order No.:
 75D0649
Manufacturer:
 TDK
Manufacturer SKU
 MLZ1608M100WT000
50 pcs.
0.11 €
250 pcs.
0.09 €
1250 pcs.
0.07 €
4000 pcs.
0.06 €
10000 pcs.
0.06 €
5.47 € *
Available: 2,878 pcs.
SMD 0603
SMD choke
0.8 mm
1.6 mm
±20 %
0.8 mm
0.01 mH
0.25 A
1.05 Ω
Choke, SMD 0603, 6.8 µH, 300 mA, MLZ1608M6R8WT000
Order No.:
 72D1243
Manufacturer:
 TDK
Manufacturer SKU
 MLZ1608M6R8WT000
4000 pcs.
0.05 €
0.00 € *
Currently not in stock, we will order for you
SMD 0603
SMD choke
0.8 mm
1.6 mm
±20 %
0.8 mm
0.0068 mH
0.3 A
0.74 Ω
Choke, SMD 0603, 1.5 µH, 550 mA, MLZ1608A1R5WT000
Order No.:
 72D1237
Manufacturer:
 TDK
Manufacturer SKU
 MLZ1608A1R5WT000
4000 pcs.
0.05 €
0.00 € *
Currently not in stock, we will order for you
SMD 0603
SMD choke
0.8 mm
1.6 mm
±20 %
0.8 mm
0.0015 mH
0.55 A
0.21 Ω
Choke, SMD 0603, 1 µH, 600 mA, MLZ1608A1R0WT000
Order No.:
 75D0639
Manufacturer:
 TDK
Manufacturer SKU
 MLZ1608A1R0WT000
9 pcs.
0.11 €
250 pcs.
0.09 €
1250 pcs.
0.07 €
4000 pcs.
0.06 €
10000 pcs.
0.06 €
0.99 € *
Available: 9 pcs.
SMD 0603
SMD choke
0.8 mm
1.6 mm
±20 %
0.8 mm
0.001 mH
0.6 A
0.15 Ω
*incl. VAT plus shipping costs
