CLF7045T-331M-D | TDK
Choke, SMD 7045, 330 µH, 490 mA, CLF7045T-331M-D
Not suitable for new designs
Unit Price (€ / pc.)
0.6188 € *
Standard delivery time from the manufacturer is: 14 Weeks
SMD choke, CLF7045T-331M-D, TDK
Features
- Magnetic shield type wound inductor for power circuits
- Compliant with AEC-Q200
- Ferrite core
Applications
- Automotive equipment
- Electronic power steering
- Headlights
- ECM
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Tolerance | ±20 % | |
| Width | 6.9 mm | |
| Saturation current | 420 mA | |
| Version | SMD choke | |
| DC current | 490 mA | |
| Length | 7.2 mm | |
| Height | 4.5 mm | |
| DC resistance | 1.236 Ω | |
| Design | SMD 7045 | |
| Measuring frequency | 100 kHz | |
| Inductance | 330 µH |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 1,000 pieces |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
