B72280B0151K001 | TDK (EPCOS)
Varistor, chassis mounting, VV 240 V, 100000 A, 200 V (DC), 150 V (AC), ±10 %, 2 VA (AC), 800 J, B72280B0151K001
Unit Price (€ / pc.)
218.1984 € *
Available: 44 pcs.
Total Price:
218.20 € *
Price list
Quantity
Price per unit*
1 pcs.
218.1984 €
5 pcs.
207.2742 €
10 pcs.
202.9188 €
20 pcs.
198.5515 €
*incl. VAT plus shipping costs
Subject to prior sale
Varistor, B72280B0151K001, EPCOS
Features
- High energy absorption capability
- Low leakage current
- Long-term ESD stability
- RoHS-compatible, lead-free
Technical specifications
| Design | chassis mounting | |
| Varistor Voltage Type | 240 V | |
| max. Surge current, transient (8/20 µs) | 100000 A | |
| Rated voltage (DC) | 200 V | |
| Rated voltage (AC) | 150 V | |
| Tolerance | ±10 % | |
| Power dissipation | 2 W | |
| Energy absorption | 800 J | |
| Grid | 32 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Standard number | UL, CSA |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85332100 |
| Original Packaging | Bulk with 5 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
