B72241L0441K100 | TDK (EPCOS)
Varistor, chassis mounting, VV 715 V, 50000 A, 585 V (DC), 440 V (AC), ±10 %, 1.4 VA (AC), 950 J, B72241L0441K100
Order No.: 82E6487
EAN: 4099879994011
MPN:
B72241L0441K100
B72241L441K100
Unit Price (€ / pc.)
14.7441 € *
Standard delivery time from the manufacturer is: 24 Weeks
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Design | chassis mounting | |
| Varistor Voltage Type | 715 V | |
| max. Surge current, transient (8/20 µs) | 50000 A | |
| Rated voltage (DC) | 585 V | |
| Rated voltage (AC) | 440 V | |
| Tolerance | ±10 % | |
| Power dissipation | 1.4 W | |
| Energy absorption | 950 J | |
| min. operating temperature | -25 °C | |
| max. operating temperature | 85 °C | |
| Standard number | UL, CSA, IEC, CECC |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bulk with 50 pieces |
| Customs tariff number | 85332100 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
