B72241L0271K100 | TDK (EPCOS)
Varistor, chassis mounting, VV 430 V, 50000 A, 350 V (DC), 275 V (AC), ±10 %, 1.4 VA (AC), 550 J, B72241L0271K100
Order No.: 82E6483
EAN: 4099879994004
MPN:
B72241L0271K100
B72241L271K100
Unit Price (€ / pc.)
12.6497 € *
Standard delivery time from the manufacturer is: 24 Weeks
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 350 V | |
| max. Surge current, transient (8/20 µs) | 50000 A | |
| Energy absorption | 550 J | |
| Rated voltage (AC) | 275 V | |
| Tolerance | ±10 % | |
| Power dissipation | 1.4 W | |
| Design | chassis mounting | |
| Varistor Voltage Type | 430 V | |
| max. operating temperature | 85 °C | |
| min. operating temperature | -25 °C | |
| Standard number | UL, CSA, IEC, CECC |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85332100 |
| Country of origin | CN |
| Original Packaging | Bulk with 50 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
