B72240B0151K001 | TDK (EPCOS)

Name: Varistor, chassis mounting, VV 240 V, 40000 A, 200 V (DC), 150 V (AC), ±10 %, 1.4 VA (AC), 360 J, B72240B0151K001
Brand: TDK (EPCOS)
SKU: 82E6445
Availability: InStock

Varistor, chassis mounting, VV 240 V, 40000 A, 200 V (DC), 150 V (AC), ±10 %, 1.4 VA (AC), 360 J, B72240B0151K001

Order No.: 82E6445

EAN: 4099879993946

MPN:

B72240B0151K001

B72240B151K1

Image may differ

Key Specification:

Design chassis mounting

Varistor Voltage Type 240 V

max. Surge current, transient (8/20 Âµs) 40000 A

Rated voltage (DC) 200 V

Rated voltage (AC) 150 V

Download Datasheet Technical specifications

Unit Price (€ / pc.)

33.3081 € *

Standard delivery time from the manufacturer is: 28 Weeks

Total Price:

1,332.32 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Technical specifications

Filter	Property	Value
	Power dissipation	1.4 W
	Rated voltage (DC)	200 V
	min. operating temperature	-40 °C
	Rated voltage (AC)	150 V
	max. Surge current, transient (8/20 Âµs)	40000 A
	max. operating temperature	85 °C
	Standard number	UL, CSA, IEC, CECC
	Varistor Voltage Type	240 V
	Tolerance	±10 %
	Design	chassis mounting
	Energy absorption	360 J
