B72232B0131K001 | TDK (EPCOS)

Name: Varistor, chassis mounting, VV 205 V, 25000 A, 170 V (DC), 130 V (AC), ±10 %, 1.2 VA (AC), 210 J, B72232B0131K001
Brand: TDK (EPCOS)
SKU: 82E6439
Availability: InStock

Varistor, chassis mounting, VV 205 V, 25000 A, 170 V (DC), 130 V (AC), ±10 %, 1.2 VA (AC), 210 J, B72232B0131K001

Order No.: 82E6439

EAN: 4099879993892

MPN:

B72232B0131K001

B72232B131K1

Image may differ

Key Specification:

Design chassis mounting

Varistor Voltage Type 205 V

max. Surge current, transient (8/20 Âµs) 25000 A

Rated voltage (DC) 170 V

Rated voltage (AC) 130 V

Download Datasheet Technical specifications

Unit Price (€ / pc.)

21.0868 € *

Standard delivery time from the manufacturer is: 28 Weeks

Total Price:

843.47 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Technical specifications

Filter	Property	Value
	Rated voltage (DC)	170 V
	max. Surge current, transient (8/20 Âµs)	25000 A
	Energy absorption	210 J
	Rated voltage (AC)	130 V
	Tolerance	±10 %
	Power dissipation	1.2 W
	Design	chassis mounting
	Varistor Voltage Type	205 V
	max. operating temperature	85 °C
	min. operating temperature	-40 °C
	Standard number	UL, CSA, IEC, CECC
