B72225S4461K101 | TDK (EPCOS)

Varistor, radial, VV 750 V, 20000 A, 615 V (DC), 460 V (AC), ±10 %, 1 VA (AC), 720 J, B72225S4461K101

Order No.: 82E3224
EAN: 4099879989154
MPN:
B72225S4461K101
Series: B72225
B72225S4461K101 TDK (EPCOS) Varistors Image 1
B72225S4461K101 TDK (EPCOS) Varistors Image 2
Image may differ
Unit Price (€ / pc.)
2.7965 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
3,355.80 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1200 pcs.
2.7965 €

Metal oxide varistors, type TDK/Epcos S25 B72225S.

Disk version

Technical specifications
Design radial
Varistor Voltage Type 750 V
max. Surge current, transient (8/20 µs) 20000 A
Rated voltage (DC) 615 V
Rated voltage (AC) 460 V
Tolerance ±10 %
Power dissipation 1 W
Energy absorption 720 J
Grid 12 mm
min. operating temperature -40 °C
max. operating temperature 85 °C
Standard number UL, CSA, VDE, IEC, IEC
Logistics
Country of origin CN
Customs tariff number 85332100
Original Packaging Bulk with 100 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
