B72220S0151K551 | TDK (EPCOS)

Name: Varistor, radial, VV 240 V, 8000 A, 200 V (DC), 150 V (AC), ±10 %, 1 VA (AC), 85 J, B72220S0151K551
Brand: TDK (EPCOS)
SKU: 82E6376
Availability: OutOfStock

Varistor, radial, VV 240 V, 8000 A, 200 V (DC), 150 V (AC), ±10 %, 1 VA (AC), 85 J, B72220S0151K551

Order No.: 82E6376

EAN: 4099879993588

MPN:

B72220S0151K551

B72220S151K551

Image may differ

Key Specification:

Design radial

Varistor Voltage Type 240 V

max. Surge current, transient (8/20 Âµs) 8000 A

Rated voltage (DC) 200 V

Rated voltage (AC) 150 V

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.9282 € *

Standard delivery time from the manufacturer is: 20 Weeks

Total Price:

1,856.40 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Technical specifications

Filter	Property	Value
	Design	radial
	Varistor Voltage Type	240 V
	max. Surge current, transient (8/20 Âµs)	8000 A
	Rated voltage (DC)	200 V
	Rated voltage (AC)	150 V
	Tolerance	±10 %
	Power dissipation	1 W
	Energy absorption	85 J
	Grid	20 mm
	min. operating temperature	-40 °C
	max. operating temperature	105 °C
	Standard number	UL, CSA, VDE, CQC, IEC
