B72214S0400K151 | TDK (EPCOS)

Name: Varistor, radial, VV 68 V, 1000 A, 56 V (DC), 40 V (AC), ±10 %, 0.1 VA (AC), 13 J, B72214S0400K151
Brand: TDK (EPCOS)
SKU: 82E6272
Availability: OutOfStock

Varistor, radial, VV 68 V, 1000 A, 56 V (DC), 40 V (AC), ±10 %, 0.1 VA (AC), 13 J, B72214S0400K151

Order No.: 82E6272

EAN: 4099879992802

MPN:

B72214S0400K151

B72214S400K151

Image may differ

Key Specification:

Design radial

Varistor Voltage Type 68 V

max. Surge current, transient (8/20 Âµs) 1000 A

Rated voltage (DC) 56 V

Rated voltage (AC) 40 V

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.4879 € *

Standard delivery time from the manufacturer is: 20 Weeks

Total Price:

1,463.70 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Technical specifications

Filter	Property	Value
	Design	radial
	Varistor Voltage Type	68 V
	max. Surge current, transient (8/20 Âµs)	1000 A
	Rated voltage (DC)	56 V
	Rated voltage (AC)	40 V
	Tolerance	±10 %
	Power dissipation	0.1 W
	Energy absorption	13 J
	Grid	14 mm
	min. operating temperature	-40 °C
	max. operating temperature	105 °C
	Standard number	UL, CSA, VDE, CQC, IEC
