B72210S2511K101 | TDK (EPCOS)
Varistor, radial, VV 820 V, 3500 A, 670 V (DC), 510 V (AC), ±10 %, 0.4 VA (AC), 80 J, B72210S2511K101
Order No.: 82E4616
EAN: 4099879989857
MPN:
B72210S2511K101
Unit Price (€ / pc.)
0.4760 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Metal oxide varistors (VDRs), type TDK/Epcos E2 B722..K101.
Advance D series for demanding pulse energy applications
Technical specifications
| Design | radial | |
| Varistor Voltage Type | 820 V | |
| max. Surge current, transient (8/20 µs) | 3500 A | |
| Rated voltage (DC) | 670 V | |
| Rated voltage (AC) | 510 V | |
| Tolerance | ±10 % | |
| Power dissipation | 0.4 W | |
| Energy absorption | 80 J | |
| Grid | 7 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Standard number | UL, CSA, VDE, CECC |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85332100 |
| Original Packaging | Bulk with 500 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
