B72210S2141K101 | TDK (EPCOS)

Name: Varistor, radial, VV 220 V, 3500 A, 180 V (DC), 140 V (AC), ±10 %, 0.4 VA (AC), 27.5 J, B72210S2141K101
Brand: TDK (EPCOS)
SKU: 82E4514
Availability: InStock

Varistor, radial, VV 220 V, 3500 A, 180 V (DC), 140 V (AC), ±10 %, 0.4 VA (AC), 27.5 J, B72210S2141K101

Order No.: 82E4514

EAN: 4099879989529

MPN:

B72210S2141K101

Image may differ

Key Specification:

Design radial

Varistor Voltage Type 220 V

max. Surge current, transient (8/20 Âµs) 3500 A

Rated voltage (DC) 180 V

Rated voltage (AC) 140 V

Download Datasheet Technical specifications

NCNR (non cancelable / non returnable)

Unit Price (€ / pc.)

0.3808 € *

Standard delivery time from the manufacturer is: 32 Weeks

Total Price:

1,142.40 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Metal oxide varistors (VDRs), type TDK/Epcos E2 B722..K101.

Advance D series for demanding pulse energy applications

Technical specifications

Filter	Property	Value
	Design	radial
	Varistor Voltage Type	220 V
	max. Surge current, transient (8/20 Âµs)	3500 A
	Rated voltage (DC)	180 V
	Rated voltage (AC)	140 V
	Tolerance	±10 %
	Power dissipation	0.4 W
	Energy absorption	27.5 J
	Grid	7 mm
	min. operating temperature	-40 °C
	max. operating temperature	85 °C
	Standard number	UL, CSA, VDE, CECC
