B72207S0170K201 | TDK (EPCOS)

Name: Varistor, radial, VV 27 V, 250 A, 22 V (DC), 17 V (AC), ±10 %, 0.02 VA (AC), 1.1 J, B72207S0170K201
Brand: TDK (EPCOS)
SKU: 82E6014
Availability: InStock

Varistor, radial, VV 27 V, 250 A, 22 V (DC), 17 V (AC), ±10 %, 0.02 VA (AC), 1.1 J, B72207S0170K201

Order No.: 82E6014

EAN: 4099879990792

MPN:

B72207S0170K201

B72207S170K201

Image may differ

Key Specification:

Design radial

Varistor Voltage Type 27 V

max. Surge current, transient (8/20 Âµs) 250 A

Rated voltage (DC) 22 V

Rated voltage (AC) 17 V

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.2261 € *

Standard delivery time from the manufacturer is: 20 Weeks

Total Price:

1,130.50 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Technical specifications

Filter	Property	Value
	Design	radial
	Varistor Voltage Type	27 V
	max. Surge current, transient (8/20 Âµs)	250 A
	Rated voltage (DC)	22 V
	Rated voltage (AC)	17 V
	Tolerance	±10 %
	Power dissipation	0.02 W
	Energy absorption	1.1 J
	Grid	7 mm
	min. operating temperature	-40 °C
	max. operating temperature	105 °C
	Standard number	UL, CSA, VDE, CQC, IEC
