B72205S2301K101 | TDK (EPCOS)
Varistor, radial, VV 470 V, 800 A, 385 V (DC), 300 V (AC), ±10 %, 0.1 VA (AC), 15 J, B72205S2301K101
Order No.: 82E4580
EAN: 4099879989727
MPN:
B72205S2301K101
Unit Price (€ / pc.)
0.2451 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Metal oxide varistors (VDRs), type TDK/Epcos E2 B722..K101.
Advance D series for demanding pulse energy applications
Technical specifications
| Design | radial | |
| Varistor Voltage Type | 470 V | |
| max. Surge current, transient (8/20 µs) | 800 A | |
| Rated voltage (DC) | 385 V | |
| Rated voltage (AC) | 300 V | |
| Tolerance | ±10 % | |
| Power dissipation | 0.1 W | |
| Energy absorption | 15 J | |
| Grid | 5 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Standard number | UL, CSA, VDE, CECC |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85332100 |
| Original Packaging | Bulk with 1,000 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
