B72205S2171K101 | TDK (EPCOS)

Name: Varistor, radial, VV 270 V, 800 A, 225 V (DC), 175 V (AC), ±10 %, 0.1 VA (AC), 8 J, B72205S2171K101
Brand: TDK (EPCOS)
SKU: 82E4530
Availability: InStock

Varistor, radial, VV 270 V, 800 A, 225 V (DC), 175 V (AC), ±10 %, 0.1 VA (AC), 8 J, B72205S2171K101

Order No.: 82E4530

EAN: 4099879989598

MPN:

B72205S2171K101

Image may differ

Key Specification:

Design radial

Varistor Voltage Type 270 V

max. Surge current, transient (8/20 Âµs) 800 A

Rated voltage (DC) 225 V

Rated voltage (AC) 175 V

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.2451 € *

Standard delivery time from the manufacturer is: 20 Weeks

Total Price:

1,225.70 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Metal oxide varistors (VDRs), type TDK/Epcos E2 B722..K101.

Advance D series for demanding pulse energy applications

Technical specifications

Filter	Property	Value
	Design	radial
	Varistor Voltage Type	270 V
	max. Surge current, transient (8/20 Âµs)	800 A
	Rated voltage (DC)	225 V
	Rated voltage (AC)	175 V
	Tolerance	±10 %
	Power dissipation	0.1 W
	Energy absorption	8 J
	Grid	5 mm
	min. operating temperature	-40 °C
	max. operating temperature	85 °C
	Standard number	UL, CSA, VDE, CECC
