B72205S0950K101 | TDK (EPCOS)

Name: Varistor, radial, VV 150 V, 400 A, 125 V (DC), 95 V (AC), ±10 %, 0.1 VA (AC), 3.4 J, B72205S0950K101
Brand: TDK (EPCOS)
SKU: 82E2308
Availability: InStock

Varistor, radial, VV 150 V, 400 A, 125 V (DC), 95 V (AC), ±10 %, 0.1 VA (AC), 3.4 J, B72205S0950K101

Order No.: 82E2308

EAN: 4099879988362

MPN:

B72205S0950K101

B72205S950K101

Image may differ

Key Specification:

Design radial

Varistor Voltage Type 150 V

max. Surge current, transient (8/20 Âµs) 400 A

Rated voltage (DC) 125 V

Rated voltage (AC) 95 V

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.2094 € *

Standard delivery time from the manufacturer is: 20 Weeks

Total Price:

1,047.20 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Metal oxide varistors (VDRs), type TDK/Epcos S05 B72205..K101.

Disk version

Technical specifications

Filter	Property	Value
	Design	radial
	Varistor Voltage Type	150 V
	max. Surge current, transient (8/20 Âµs)	400 A
	Rated voltage (DC)	125 V
	Rated voltage (AC)	95 V
	Tolerance	±10 %
	Power dissipation	0.1 W
	Energy absorption	3.4 J
	Grid	5 mm
	min. operating temperature	-40 °C
	max. operating temperature	85 °C
	Standard number	UL, CSA, SEV, VDE, CECC, CQC, IEC
