B72205S0170K101 | TDK (EPCOS)

Name: Varistor, radial, VV 27 V, 100 A, 22 V (DC), 17 V (AC), ±10 %, 0.01 VA (AC), 0.5 J, B72205S0170K101
Brand: TDK (EPCOS)
SKU: 82E2302
Availability: InStock

Varistor, radial, VV 27 V, 100 A, 22 V (DC), 17 V (AC), ±10 %, 0.01 VA (AC), 0.5 J, B72205S0170K101

Order No.: 82E2302

EAN: 4099879988331

MPN:

B72205S0170K101

B72205S170K101

Image may differ

Key Specification:

Design radial

Varistor Voltage Type 27 V

max. Surge current, transient (8/20 Âµs) 100 A

Rated voltage (DC) 22 V

Rated voltage (AC) 17 V

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.2094 € *

Standard delivery time from the manufacturer is: 20 Weeks

Total Price:

1,047.20 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Metal oxide varistors (VDRs), type TDK/Epcos S05 B72205..K101.

Disk version

Technical specifications

Filter	Property	Value
	Design	radial
	Varistor Voltage Type	27 V
	max. Surge current, transient (8/20 Âµs)	100 A
	Rated voltage (DC)	22 V
	Rated voltage (AC)	17 V
	Tolerance	±10 %
	Power dissipation	0.01 W
	Energy absorption	0.5 J
	Grid	5 mm
	min. operating temperature	-40 °C
	max. operating temperature	85 °C
	Standard number	UL, CSA, SEV, VDE, CECC, CQC, IEC
