B72205S0151K101 | TDK (EPCOS)
Varistor, radial, VV 240 V, 400 A, 200 V (DC), 150 V (AC), ±10 %, 0.1 VA (AC), 4.9 J, B72205S0151K101
Order No.: 82E2231
EAN: 4099879987990
MPN:
B72205S0151K101
B72205S151K101
Unit Price (€ / pc.)
0.2094 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Metal oxide varistors (VDRs), type TDK/Epcos S05 B72205..K101.
Disk version
Technical specifications
| Design | radial | |
| Varistor Voltage Type | 240 V | |
| max. Surge current, transient (8/20 µs) | 400 A | |
| Rated voltage (DC) | 200 V | |
| Rated voltage (AC) | 150 V | |
| Tolerance | ±10 % | |
| Power dissipation | 0.1 W | |
| Energy absorption | 4.9 J | |
| Grid | 5 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Standard number | UL, CSA, SEV, VDE, CECC, CQC, IEC |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85332100 |
| Original Packaging | Bulk with 1,000 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
