B59201P1120A062 | TDK (EPCOS)
PTC thermistor, 4.6 Ω, 120 °C, ±25 %, SMD 3225, B59201P1120A062
Unit Price (€ / pc.)
1.5113 € *
Available: 970 pcs.
Leadtime: On Request **
Total Price:
1.51 € *
Price list
Quantity
Price per unit*
1 pcs.
1.5113 €
50 pcs.
1.3328 €
100 pcs.
1.1424 €
500 pcs.
1.0115 €
1000 pcs.
0.9282 €
*incl. VAT plus shipping costs
**Subject to prior sale
SMD PTC thermistors, type TDK/Epcos B59.
In plastic mold, suitable for overload and short-circuit protection, with tinned leads for flow and reflow soldering
Operating voltage 30 V/60 °C and reference temperature of 120 °C, type B59101../B59201../B59301.
Technical specifications
| ohmic resistance | 4.6 Ω | |
| Response temperature | 120 °C | |
| Tolerance | ±25 % | |
| Design | SMD 3225 | |
| Rated voltage (DC) | 30 V | |
| Rated voltage (AC) | 30 V | |
| Rated current | 265 A | |
| switching current | 545 mA | |
| Assembly | SMD | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 125 °C |
Download
Logistics
| Country of origin | ID |
| Customs tariff number | 85332100 |
| Original Packaging | Reel with 1,000 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
