B57364S0409M051 | TDK (EPCOS)
NTC, 4 Ω, ±20 %, 5.1 W, 0.024 W/K, 100 s, THT, B57364S0409M051
 Order No.: 82E5323
  EAN: 4099879979056
  MPN:
  B57364S0409M051
  B57364S409M51
 Unit Price (€ / pc.)
   1.8326 €  *
   Standard delivery time from the manufacturer is: 20 Weeks
  Technical specifications

 | Filter | Property | Value |
|---|---|---|
| ohmic resistance | 4 Ω | |
| max. operating temperature | 170 °C | |
| min. operating temperature | -55 °C | |
| Assembly | THT | |
| Grid | 7.5 mm | |
| Cooling time constant (air) | 100 s | |
| Power | 5.1 W | |
| Thermal conductivity (Air) | 0.024 W/K | |
| Tolerance | ±20 % |
 Download
  Logistics

 | Property | Value |
|---|---|
| Customs tariff number | 85332100 |
| Original Packaging | Reel with 1,000 pieces |
| Country of origin | CN |
 Compliance

 | Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
