B84143B0150S024 | TDK (EPCOS)
EMC filter, 50 to 60 Hz, 150 A, 400/690 VAC, terminal block, B84143B0150S024
Order No.: 74D8043
EAN: 4099889078510
MPN:
B84143B0150S024
B84143B150S24
Unit Price (€ / pc.)
914.8958 € *
Standard delivery time from the manufacturer is: 7 Weeks
EMC filter, B84143B0150S024, EPCOS
3-line filter for converters and power electronics
Features
- Easy to install
- Very compact design
- Low weight
Applications
- Frequency converters for motor drives
- Wind farms
- Power supplies
Technical specifications
| max. frequency | 60 Hz | |
| Number of phases | 3 | |
| integrated switch | No | |
| Rated current | 150 A | |
| With fuse | No | |
| Version | EMC filter | |
| min. operating temperature | -25 °C | |
| Connection | terminal block | |
| Rated Voltage | 400/690 VAC | |
| max. operating temperature | 100 °C | |
| min. frequency | 50 Hz | |
| ohmic resistance | 140 mΩ |
Download
Logistics
| Country of origin | HU |
| Customs tariff number | 85363010 |
| Original Packaging | Carton with 1 piece |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
