B84142J0250S081 | TDK (EPCOS)
EMC filter, 250 A, 1000 V (DC), bus bar, B84142J0250S081
Order No.: 74D7981
EAN: 4099889078268
MPN:
B84142J0250S081
B84142J250S81
Unit Price (€ / pc.)
667.1854 € *
Standard delivery time from the manufacturer is: 8 Weeks
EMC filter, B84142J0250S081, EPCOS
2-line filter for converters and power electronics
Features
- High insertion loss
- Very low power loss
- High DC voltage
- Low weight
Applications
- Photovoltaic modules
- Wind farms
- Power supplies
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ohmic resistance | 0.11 mΩ | |
| max. operating temperature | 100 °C | |
| Rated voltage (DC) | 1000 V | |
| Connection | bus bar | |
| With fuse | No | |
| Rated current | 250 A | |
| min. operating temperature | -25 °C | |
| integrated switch | No | |
| Version | EMC filter |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | HU |
| Original Packaging | Carton with 1 piece |
| Customs tariff number | 85363010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
