B84142C0600S081 | TDK (EPCOS)
EMC filter, 600 A, 1500 V (DC), bus bar, B84142C0600S081
Order No.: 74D7976
EAN: 4099889078251
MPN:
B84142C0600S081
B84142C600S81
Unit Price (€ / pc.)
932.2579 € *
Standard delivery time from the manufacturer is: 7 Weeks
EMC filter, B84142C0600S081, EPCOS
2-line filter for converters and power electronics
Features
- High insertion loss
- Very low power loss
- High DC voltage
- Low weight
Applications
- Photovoltaic modules
- Wind farms
- Power supplies
Technical specifications
| Rated voltage (DC) | 1500 V | |
| integrated switch | No | |
| Rated current | 600 A | |
| With fuse | No | |
| Version | EMC filter | |
| min. operating temperature | -25 °C | |
| Connection | bus bar | |
| max. operating temperature | 100 °C | |
| ohmic resistance | 0.043 mΩ |
Download
Logistics
| Country of origin | HU |
| Customs tariff number | 85363010 |
| Original Packaging | Carton with 1 piece |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
