B84142A0010R000 | TDK (EPCOS)

EMC filter, 50 to 60 Hz, 10 A, 250 VAC, terminal block, B84142A0010R000

Order No.: 74D7939
EAN: 4099889078152
MPN:
B84142A0010R000
B84142A10R
B84142A0010R000 TDK (EPCOS) Interference suppression filter
Image may differ
Unit Price (€ / pc.)
62.7487 € *
Standard delivery time from the manufacturer is: 8 Weeks
Total Price:
1,003.98 € *
*incl. VAT plus shipping costs
Subject to prior sale
16 pcs.
62.7487 €

EMC filter, B84142A0010R000, EPCOS

2-line filter for converters and power electronics

Features

  • High insertion loss
  • Easy to install
  • Degree of protection: IP 20
  • Very compact design
  • Optimized for long motor cables and operation under full load

Applications

  • Frequency converters for motor drives
  • Elevators
  • Traction and conveyor system
  • HVAC system (heating, ventilation and air conditioning)
  • Power supplies
  • DC applications
Technical specifications
Filter Property Value
max. frequency 60 Hz
Number of phases 1
integrated switch No
Rated current 10 A
With fuse No
Version EMC filter
min. operating temperature -25 °C
Connection terminal block
Rated Voltage 250 VAC
max. operating temperature 100 °C
min. frequency 50 Hz
ohmic resistance 18 mΩ
Logistics
Property Value
Country of origin HU
Customs tariff number 85363010
Original Packaging Bulk with 16 pieces
Compliance
Property Value
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
